Lorenz Lo10UK39 Antenna-Box

This is the Lo10UK39 Antenna-Box every Lo10UK39 would have had this box wich could be installed inside but also outside because it is weatherproof.

On this side the the type plate and the connector are visible. This is where the Lo10UK39 would be connected but the connector is sadly missing. In fact the complete inside is sadly empty wich is why I have posted no pictures of the inside.

Here a better view of the Type plate and the mounting points. Below the Type plate is a Kriegsmarine Stamp.

On the side 3 large bolts can be seen. This is where the counter weights would have been installed on both sides. I sadly do not own these.

Here the actual connector and Isolator to the antenna can be seen. It is very largen just like the complete box even though the Transmitter only delivers 10 Watts.

This is the only part I own that belongs on the inside. all the rest is missing. A diode and some other parts are inside this case.

Here one last top view. another marking can be seen as well as the bolts to open the lid. These too are very heavy duty and below the lid is a rubber seal to weather proof the whole box.
